GOALS

Engineer and implement independent production capacities to provide the whole American FFS market with thermoformable plastic sheets for food safety applications as well as for the electronics and medical equipment sectors and thermoformable consumers at large. By distributing our production quotas among 4 sites, we have become an efficient industrial powerhouse that specializes in delivering reels of thermoformable plastic Sheets.

Acquire enough international stature to be able to reach and interact with our customers at their own development sites.

MEANS

Install production capacity for sheet.

  • CEDAP THERMOFORMABLE PLASTIC SHEETS
  • CEDAP THERMOFORMABLE PLASTIC SHEETS
  • CEDAP THERMOFORMABLE PLASTIC SHEETS
  • CEDAP THERMOFORMABLE PLASTIC SHEETS

CEDAP PRODUCTION PLANT

TECHNICAL DESCRIPTION

- Total Area: 27,555 sq ft
- Manufacturing Area: 13,832 sq ft
- Warehousing Area: 9,365 sq ft
- Office Space: 1,991 sq ft
- Maintenance: 807 sq ft

CEDAP uses only raw materials from producers that can guarantee: - Food contact compliance of all components (both plastic and dyes) - Full tracing - Uniformity of all mechanical characteristics during thermoforming.

Production Snap-shot

  • 1

    Raw Material

  • 2

    Extrusion

  • 3

    Automatic Die

  • 4

    Reeling, packing

  • CEDAP THERMOFORMABLE PLASTIC SHEETS CEDAP THERMOFORMABLE PLASTIC SHEETS CEDAP THERMOFORMABLE PLASTIC SHEETS CEDAP THERMOFORMABLE PLASTIC SHEETS

    Raw Material

    Cedap sources its raw materials only from manufacturers that can assure:

    - Food Contact Compliance of all components
    (plastic and dies)

    - Full Tracing

    - Uniformity in Mechanical properties during thermoforming.

  • CEDAP THERMOFORMABLE PLASTIC SHEETS CEDAP THERMOFORMABLE PLASTIC SHEETS CEDAP THERMOFORMABLE PLASTIC SHEETS CEDAP THERMOFORMABLE PLASTIC SHEETS

    Extrusion

    Approaching a milestone of 50 years experience in plastic sheets extrusion.

  • CEDAP THERMOFORMABLE PLASTIC SHEETS CEDAP THERMOFORMABLE PLASTIC SHEETS CEDAP THERMOFORMABLE PLASTIC SHEETS CEDAP THERMOFORMABLE PLASTIC SHEETS

    Automatic die

    To conduct automated tolerance tests The drawing die consists of two die lips:
    - a “fixed” lower lip that operators adjust only to preset,
    - an upper lip that can be adjusted manually or automatically.

    The gap between the two lips -called the air gap- depends on the desired thickness of the product.
    The upper lip can be adjusted thanks to 66 heating bolts cartridges that are distributed all along the top of the die lip. The heating bolts cartridges have to be adjusted one at a time, either manually by the operator by means of a key, or by "heating/cooling". While heating causes the heating bolt cartridges to dilate and the die lip to close.

    At the calender's exit, the extrusion unit is equipped with a scanner that continuously measures the sheet thickness. The measurements are displayed on the screen of the control system, and the information is then processed by the system that induces the opening or closing of an area of the upper die lip according to the measured thickness, in order to guarantee an extruded section of regular and constant thickness. At the same time, according to the measured average thickness, the system automatically accelerates or decelerates the calender, to guarantee an average thickness within a specified range.

  • CEDAP THERMOFORMABLE PLASTIC SHEETS CEDAP THERMOFORMABLE PLASTIC SHEETS CEDAP THERMOFORMABLE PLASTIC SHEETS CEDAP THERMOFORMABLE PLASTIC SHEETS

    Reeling, packaging

    Each reel is packaged, weighed, labelled and placed on a pallet or on a pedestal according to the customers' specifications.
